The old furnace was oversized. That is the single most common thing we find when we measure a Lower Mainland house that is about to switch to a heat pump. Somebody matched the new equipment to the old equipment twenty years ago, and the old equipment was matched to the one before that.

Heat pumps punish that habit in a way furnaces never did. A furnace that is too big burns hot, shuts off, and mostly annoys you. A heat pump that is too big short-cycles, never pulls humidity out of the air in August, wears its compressor, and — in a variable-capacity Carrier system — spends its life running at the bottom of a modulation range it was never meant to sit in.

So the sizing conversation is the install. Everything else is bolts and refrigerant. This page walks through what actually goes into sizing a Carrier heat pump for a house in Metro Vancouver or the Fraser Valley: the calculation, the inputs that move the number, the duct reality check, and the questions to ask whoever hands you a quote.

What a heat loss and heat gain calculation actually measures

It measures energy leaving your house on the coldest hour of a normal winter, and energy entering it on the hottest afternoon of a normal summer. Those are two different numbers, and a heat pump has to serve both.

The technician walks the house with a tape measure and a clipboard, or a tablet. Every exterior wall gets measured and assigned an insulation value based on construction era and anything visible in the attic or crawlspace. Every window gets counted, sized, and classified: single pane, double, low-e coating, which direction it faces. South and west glass drives the cooling number hard in a Fraser Valley summer. Ceiling insulation depth. Floor construction over a crawlspace versus a slab. Door count. Ceiling height, because a 1970s rancher and a modern home with a two-storey entry have very different volumes behind the same footprint.

Then come the parts people forget: air leakage, which is a real estimate based on age and any blower door data you have, and internal gains from people, cooking and appliances.

The output is a load in BTU per hour for heating and another for cooling, broken out room by room. Room-by-room matters. It tells you whether that bonus room over the garage needs its own solution, and it tells the installer how much air each register actually has to deliver.

Why square-footage rules of thumb fail on Lower Mainland housing stock

Rules of thumb assume one house. This region does not have one house.

A 1955 bungalow in Burnaby with original single-pane windows and knob-and-tube-era wall cavities has a wildly different load than a 2019 build in Langley with a sealed envelope and triple glazing at the same square footage. Both would get the same answer from a per-square-foot table. One of those answers would be badly wrong.

The East Vancouver character home with an unheated attic and a finished basement suite is a third case entirely, because the suite changes both the load and how the air has to be distributed. A West Vancouver house cut into a slope with two walls against earth loses heat differently than a freestanding one. A Richmond home on a crawlspace over high water table sits in damp air most of the winter.

There is also a strata factor. Townhouses share walls, and shared walls barely lose heat. A middle unit in a Coquitlam townhouse row can have a dramatically lower heating load than the identical end unit two doors down. Size them the same and one of them short-cycles all winter.

Renovation history compounds all of it. Somebody replaced the windows in 2014. Somebody blew insulation into the attic. Somebody finished the basement without insulating the rim joist. None of that shows up in square footage, and all of it shows up in the load.

Cold-climate capacity and what happens to output as it gets colder

A heat pump does not have one capacity. It has a curve.

At mild outdoor temperatures a heat pump produces more heat than its nameplate suggests. As outdoor air gets colder, there is less heat in it to move, and output falls. Every manufacturer including Carrier publishes extended performance data showing rated capacity at a series of outdoor temperatures for each specific model. That table, not the tonnage on the box, is what a proper sizing exercise uses. Ask to see it for the model being quoted, and check it against the manufacturer’s published data for that exact model number.

Greater Vancouver is genuinely favourable here. Our winter design conditions are far milder than most of Canada, which means a well-selected cold-climate heat pump holds a large share of its capacity through the coldest stretches we normally see. That is why heat pumps make sense here in a way they do not everywhere.

But “normally see” is doing work in that sentence. Fraser Valley communities inland — Abbotsford, Chilliwack, Mission — run colder than the coast, and an outflow event through the Fraser Canyon can drop temperatures well below anything Vancouver proper experiences. Elevation matters too. A house on the North Shore slopes or up in Coquitlam’s higher neighbourhoods sees colder nights than one near the water.

Sizing should be done against the design condition for your actual location, not a regional average.

The balance point, and deciding how much backup heat you want

The balance point is the outdoor temperature where your heat pump’s output exactly equals your house’s heat loss. Above it, the heat pump carries the whole house. Below it, something else has to make up the difference.

You get to choose where that point sits, and the choice is a real tradeoff.

Size the heat pump to cover the full heating load right down to design temperature, and you may end up with equipment that is oversized for the mild weather where it spends ninety-five percent of its hours. It short-cycles in spring and fall and does a poor job of dehumidifying in summer. Size it smaller, with a lower balance point, and it runs long steady cycles most of the year — which is what heat pumps do best — but leans on backup heat during genuine cold snaps.

A variable-capacity Carrier system widens the comfortable range considerably, because it can throttle down instead of cycling. That changes the calculus and usually lets you size closer to the heating load without the short-cycling penalty.

Backup comes in a few forms. Electric resistance strips in the air handler. A gas furnace retained as the backup stage in a dual-fuel setup. In an older Vancouver home already on gas, keeping the furnace as backup is often the cleanest answer, and it means electrical service work may be unnecessary. Dual fuel needs a proper changeover strategy and a control that manages it — that is a technician setup, not a homeowner setting.

Ductwork: the constraint that overrules the calculation

You can calculate a perfect equipment size and still be wrong, because the ducts have a vote.

A heat pump moves more air than a furnace to deliver the same heat, because it delivers that heat at a lower supply temperature. Furnace air comes out hot. Heat pump air comes out warm. To move equivalent energy, volume has to go up. Duct systems designed decades ago around a hot-supply furnace are frequently too small for that.

What happens if you ignore it: high static pressure, a blower fighting the system, noise at the registers, uneven room temperatures, reduced capacity, and a compressor working harder than it should. The equipment is right and the install still fails.

So a proper sizing visit includes a look at the trunk and branch sizing, the return path in particular, and often a static pressure reading on the existing system before anything is ordered. Returns are usually the bigger problem. Older Lower Mainland homes commonly have one undersized central return, sometimes a single hallway grille trying to feed the whole house.

Sometimes the fix is modest: enlarge the return, add a second return, resize a couple of branches. Sometimes a room simply cannot be served properly by the existing duct and a ductless head is the honest answer for that space.

Crawlspace and attic duct runs in this climate also need their insulation and sealing checked. Damp crawlspaces are hard on duct insulation.

Outdoor unit placement, strata rules and coastal corrosion

Placement is part of sizing in practice, because where the unit can legally and physically go sometimes limits what you can install.

Start with noise. Most Metro Vancouver municipalities have noise bylaws with lower nighttime limits, and setback or sound requirements vary by city. Strata corporations layer their own rules on top, and many require an alteration agreement before anything gets bolted to a wall or set on a patio. Get that approval in writing before ordering equipment. We have seen units sit in a garage for weeks waiting on a council meeting.

Airflow around the unit matters more than people expect. An outdoor unit needs clear space to breathe and needs room above it for discharge. Tucking it into a narrow side yard between two houses — extremely common on Vancouver lots — can cause it to recirculate its own discharge air and lose capacity. That is a real derate, not a theoretical one.

Defrost is the other placement issue. Heat pumps shed water during defrost cycles, and in our winters they defrost often. That water has to drain somewhere that will not ice over a walkway. Units near the ground want a stand and a plan for the meltwater.

Salt air is the last one. Homes near the water in White Rock, Tsawwassen, Steveston, along the North Shore waterfront — outdoor coils corrode faster there. Ask about coil protection options and factor in more frequent coil rinsing.

Matching indoor and outdoor components as a rated system

Sizing is not just picking an outdoor unit. The indoor coil or air handler, the outdoor unit and the control are rated together as a system, and the performance numbers only apply to combinations the manufacturer actually tested.

This matters in two ways.

First, efficiency and capacity ratings are published for specific matched combinations, listed through AHRI. A given Carrier outdoor unit paired with air handler A performs differently than the same unit paired with air handler B. If a quote gives you an efficiency figure, ask which AHRI-listed combination it refers to and confirm it against the listing for those exact model numbers. Rating systems for heat pumps cover both heating and cooling seasonal performance; check the manufacturer’s spec sheet for your specific match.

Second, warranty and controls. Manufacturers generally expect matched components, and mismatched systems can create coverage questions. Verify with Carrier or your installing contractor what the requirements are for the model you are buying.

A common Lower Mainland scenario: keeping an existing gas furnace and adding a heat pump above it, with the indoor coil sitting on the furnace. That can work well and is the backbone of most dual-fuel installs here. But the furnace blower has to be capable of the airflow the heat pump needs, and an older single-speed blower often is not. Check it before assuming the furnace stays.

The control ties it together and needs to be one that actually manages heat pump staging and changeover.

What to ask for before you sign, and what the estimate should show

Ask for the load calculation. Not a summary, the actual output. It should show heating and cooling loads, the assumptions used for insulation and windows, and a room-by-room breakdown. If a contractor cannot produce one, they sized by eye.

Ask which design temperature they used and why. It should reflect your municipality, not a generic provincial number.

Ask for the extended capacity table for the specific Carrier model quoted, showing output at several outdoor temperatures, and ask where the balance point lands for your house. Then ask what happens below it — electric strips, retained gas furnace, something else — and what the changeover setup will be.

Ask what they found on the ducts. A static pressure reading, a note on return capacity, and a plan for any room the existing duct cannot serve.

Ask about placement: exact location, clearances, noise expectations relative to your municipal bylaw and any strata rules, drainage plan for defrost water, and whether coil protection is worth it at your address.

Ask what permits apply, what electrical work is needed, and who pulls what. Ask what documentation you will get for CleanBC or FortisBC program applications — confirm current program requirements directly with those programs, since eligibility rules change.

HeatLand has been sizing and installing heating systems across Metro Vancouver and the Fraser Valley since 1999. We are licensed and insured, TSBC-certified for gas fitting, and we service all major brands. Call (604) 330-3812 for a free written no-obligation estimate.

Quick Checklist

• Get a room-by-room heat loss and heat gain calculation in writing before any equipment is chosen
• Confirm the design temperature used matches your municipality, not a regional average
• Review the extended capacity table for the exact Carrier model quoted, not just the tonnage
• Decide your balance point and backup heat strategy deliberately — electric strips or retained gas furnace
• Have static pressure measured and return-air capacity assessed on the existing duct system
• Verify strata approval and municipal noise bylaw compliance before ordering the outdoor unit
• Plan outdoor unit clearances, discharge airflow and defrost meltwater drainage
• Confirm the indoor and outdoor components are an AHRI-listed matched combination
